SJ65 HDPE LDPE PP Film Cold Strand Pelletizing Granulating System
Introduction
* This SJ65 HDPE LDPE PP Film Cold Strand Pelletizing Granulating System is designed and manufactured by Friend Machinery, which is widely
used for waste plastic PE PP soft material, such as clean HDPE,
LDPE, LLDPE film flakes, clean PP woven bag, etc.
* The material go through compressing system, plasticizing
system,water cooling system, pelletizing system and collect system
will turn to be clean perfect pellets for reuse.
* You can choose twin stages or single stage extruder according to
the cleanliness of your material condition and capacity
requirements.
* This plastic pelletizing line can be displayed "L" or "U" shape
according to clients' workshop size .
* We also provide plastic crushing washing recycling line to get
clean dry flakes or film from dirty waste material.
* We can also customize the pelletizing line according to client's
material and product requirement.
* Working Flow (Strand-Cooling Cutting Pelletizing Line)
* Features
1. Automatically working, conveying material, plasticizing,
extruding, cooling, drying, cutting, collecting.
2. High efficiency, safety control, capacity from 150-1000 kg/h.
* Processing
Worker put film or bag into Agglomerator---------plastic
ball---------screw loader feeds plastic into extruder
hopper----------extruder plasticizing process( vent screw
)---------Hydraulic network(for impurity sorting)-----
----Mold ( for 3mm diameter pellet ) ---------water bath
cooling--------forcecoolingfan ( for cooling and
water blowing )---------pelletizer (could adjust pellet length by
adjusting cutting speed )---------Vibrating
Screen ( for sorting good quality and size pellet )
---- Compactor: With multi blades crushing and compulsively
compress the film into extruder.
---- Single Screw Extruder : Plasticizing material with high
temperature and exhausting hot gas.
---- Hydraulic Screen Exchanger: Filter material impurity to make
production more stable.
---- Die Mold: Materials come out in long strand.
---- Water Cooling Tank: Cooling the strap with cold water.
---- Force Air Drying System: Drying the strand.
---- Pelletizer Cutter: Cutting the strap into pellets with high
speed rotation.
---- Vibration Screen: Pick out bad pellets and keep good pellets.
---- Air Blower: Blower push pellets into the silo.
---- Storage Silo: Collecting pellets, made by high quality
stainless steel
---- Control Cabinet: Control the whole line on/off (adopt famous
brand such as Schneider, Siemens, etc.)
* Technical Parameter
| Model | Screw Diameter | Screw L/D | Main Motor Power | Capacity |
| SJ65 | 65mm | 30:1 | 37kw | 80-100KG/h |
| SJ85 | 85mm | 30:1 | 55kw | 150-200kg/h |
| SJ100 | 100mm | 30:1 | 75kw | 200-300 kg/h |
| SJ130 | 130mm | 30:1 | 90-110kw | 300-400 kg/h |
| SJ150 | 150mm | 25-35:1 | 110-132kw | 400-500 kg/h. |
| SJ160 | 160mm | 25-35:1 | 132-160kw | 600-800 kg/h |
| SJ180 | 180mm | 25-35:1 | 160-200kw | 800-1000 kg/h |
Clause & Service:
Installation and Debugging:
Pre-sale: we given client the details technician offer, sign the
sales contract etc.
In-sales: we supply the details layout, installation instruction,
technician support for the clients.
After sales: we arrange engineer to install the machinery and
training the workers for client. We always up date the new
technology to every customer.
Delivery and Shipping:
After the contract comes into effect, buyer pay deposit, we will
start to produce. When all the machines are completed, buyers come
to factory to observe and test machine by themselves, until all the
machines are satisfied with the buyers, they can pay for the other
balance. Our company arrange to shipping goods to buyer. We provide
the goods to be shipped by air or by sea. Pictures of cargo loading
will be sent to every client to check and keep recording.
Package:
Packing with film, pallet or wooden case.(according to customers'
request).
Guarantee:
We provide one-year warranty guarantee for all the machines. We
supply long term spare parts for every customer.
Certificate: CE, ISO9001.2008.
