Waste PP PE Plastic Pulverizer Machine Plastic Grinding Machine
Plastic Pulverizer Machine
Description
1. The new disc design is with high quality, strong resistance and
the life of this grinding disc is double the ordinary ones.
2. The newly designed professional bearings, is with a high
rotation rate. At the same time using only one drive motor, to
ensure the efficient grinding crash, which greatly saves the time
of machine operation and engineering control.
3. Easy installation and maintenance, just open the door to clean
up.
4. The whole milling process is sealed, without dust leakage.
5. Full automatic design, automatically feeding, discharging and
sorting.
6. Grinding gap adjustment is simple, just use the feeler gauge and
adjust bolts can be fine tuning.
7. The mill use the water and wind double cooling system.
8. With a wide range of optional accessories, professional
solutions can be developed based on the customer's budget and
processing requirements.
Advantages
1. Safe and simple adjustment of cutting gap
2. Low energy consumption and high throughput
3. Innovative and energy efficient design
4. Easy to maintain and control
5. Wide range of accessories
6. Regrinding coarse powder automatically
7. Dual cooling system
Features
1. It is the solid structure, cover small area, it is an
independent producting system from primary material to the final
powder.
2. Fineness of the final powder is well-distributed, 99% of them
can pass through the screen, other milling machines are hard to
approach.
3. Raymond mill conmission equipment adopt closed gear case and
pulley, stable convey and believable work.
4. Important part adopt high quality steel, abrasion proof adopt
high quality abrasion material, the whole machine have a high
abrasion and have a believable work.
5. Its electric system adopt concentrating control, the workshop
can realize no-people work, and maintance, etc.
Main Technical Parameters
| Model | SMF-400B | SMF-500B | SMF-600B | SMF-800B |
| Motor Power(kw) | 30 | 37 | 55 | 75 |
| Blad disk diameter(mm) | 400 | 500 | 600 | 800 |
| Rotary blades(PCS) | 24 | 24 | 28 | 36 |
| Finial powder size(mesh) | 10-60 | 10-60 | 10-60 | 10-60 |
| Capacity(kg/h) | 60-100 | 120-220 | 180-300 | 250-450 |
