Brand Name : | Friend |
Model Number : | FLD-65-M |
Certification : | CE |
Price : | Usd 90,000 Set |
Payment Terms : | L/C, T/T |
Supply Ability : | 1+Set+per 45days |
Delivery Time : | 15 work days |
The production line mainly includes: SJ-65 extruder, mold, melt pump, screen changer, winding and cutting machine, and air heating system. The meltblown nonwoven making process uses high-speed hot air to draw a thin stream of polymer melt extruded from the spinneret of the die, thereby forming ultra-fine fibers and condensing on the curtain web, and relying on self-adhesion to become Non-wovens.
Model | Screw Diameter | Screw Rotation Speed | Extruder Motor Power | Barrel Heating Power | Capacity |
SJ-65 | 65mm | 20-150(r/min) | 30kw | 16kw | 350-400kg/day |
No | Name | Quanity |
1 | SJ65/30 Single Screw Extruder (With auto loader and hopper dryer) | 1 set |
2 | hydraulic screen changer | 1 set |
3 | melt metering pump | 1 set |
4 | mold | 1 set |
5 | Net curtain cloth collecting device | 1 set |
7 | Cutting and winding device | 1 set |
8 | Air heating system | 1 set |
Non-woven Mechanical Application
,
![]() |
